ERW273 Tube mil/oipe mil/welded pipe production/pipe making machine is used to Produce steel pines of 114mm～273mm in OD and 2.0mm～10.0mm in wall thickness, as well as corresponding round tube, square tube and special-shaped tube.
Application: Gl, Construction, Automotive, General Mechanical tubing, Furniture, Agriculture, Chemistry, 0il, Gas, Conduit, Contructur
|
Product |
ERW273mm Tube Mill |
|
Applicable Material |
HR/CR,Low Carbon Steel Strip Coil,Q235,S2 35,Gi Strips. ab≤550Mpa,as≤235MPa |
|
Pipe cutting Length |
3.0～12.0m |
|
Length Tolerance |
±1.0mm |
|
Surface |
With Zinc Coating or without |
|
Speed |
Max.Speed:≤40m/min (can customized according to customer's re quirements) |
|
Others |
All the pipe is high frequency welded Both inner and outer welded stab has been removed |
|
Material of roller |
Cr12 or GN |
|
Squeeze roll |
H13 |
|
Scope of welded pipe equipm ent |
Hydraulic double-Mandrel un-coiler Hydraulic Shear&Automatic Welding Horizontal Accumulator Forming&Sizing Machine Electric Control System Solid State H.F.Welder (AC or DC Driver) Computer Flying Saw/Cold Cutting Saw Run Out table |
|
All auxiliary equipment and accessories, such as uncoiler, motor, bearing, cut ting saw, roller, hf,etc., All are top brands. The quality can be guaranteed. |
|
